DAHUA DH-XVR1B04-I 4 CH PENTA BRID

Industrial-grade processor

Embedded Linux

Web; Local GUI

4 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change

4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

1. CVI: 1080p@25/30 fps; 720p@50/60 fps; 720p@25/30 fps.

2. TVI: 1080p@25/30 fps; 720p@25/30 fps.

3. AHD: 1080p@25/30 fps; 720p@25/30 fps.

Up to 5 channels of IPC access

1 IP channel by default + 4 channels (analog channels are converted to IP channels)

Incoming bandwidth: 20 Mbps, recording bandwidth: 20 Mbps and outgoing bandwidth: 20 Mbps

*After IP extension is enabled, the AI Function (SMD) will be disabled.

Main stream: 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps)

Sub stream: CIF@(1 fps–15 fps)

Yes

32 kbps–4096 kbps

8 kHz, 16 bit

64 kbps

1 HDMI, 1 VGA

HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720

VGA: 1920 × 1080, 1280 × 1024, 1280 × 720

When IP extension mode not enabled: 1/4

When IP extension mode enabled: 1/4/6

Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF

AI Coding; Smart H.265+; H.265; Smart H.264+; H.264

G.711a; G.711u; PCM

HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)

iOS; Android

ONVIF 22.12 (Profile T; Profile S; Profile G); CGI; SDK

Chrome; IE; Safari; Edge; Firefox

General; alarm; motion detection

1/4

USB device and network

Instant playback; general playback; event playback; tag playback; smart playback

Motion detection; HDCVI alarm; camera external alarm; network alarm; PIR alarm

Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline

SMD Plus

Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email

1-channel RCA

4-channel BNC (Coaxial Audio)

1-channel RCA

Yes (share the same audio input with the first channel)

1 SATA port, up to 6 TB. This limit varies depending on the environment temperature.

2 (2 rear USB 2.0 ports)

1

1

1 (10/100 Mbps Ethernet port, RJ-45)

12 VDC, 1.5 A

<7 W (without HDD)

0.55 kg (1.19 lb)

0.97 kg (2.11 lb)

197.0 mm × 203.1 mm × 41.5 mm (7.76″ × 8.00″ × 1.63″) (W × D × H)

332.0 mm × 64.0 mm × 240.0 mm (13.07″ × 2.52″ × 9.45″) (W × D × H)

–10 °C to +45 °C (+14 °F to +113 °F)

–20 °C to +60 °C (–4 °F to +140 °F)

10%–90% (RH), non-condensing

Desktop

CE-LVD: IEC 62368-1:2014

CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
